Inverse Kinematics

Inverse Velocity Kinematics

Implemention (Core M7)

void InverseKinematic(float cmd_linvel, float cmd_angvel, float wheel_distance, float wheel_radius)
{
    float right_speed, left_speed;  // unit: m/s
    right_speed = cmd_linvel + cmd_angvel*wheel_distance*0.5;
    left_speed = cmd_linvel - cmd_angvel*wheel_distance*0.5;
    // m/s to rpm
    RightMotor_CmdVel = (right_speed * 60) / (wheel_radius * 2 * M_PI);
    LeftMotor_CmdVel = (left_speed * 60) / (wheel_radius * 2 * M_PI);
    // Saturate motor if speed is too much
    uint8_t sat_value = 15;
    if (fabs(RightMotor_CmdVel) > sat_value){
        if (RightMotor_CmdVel > 0){
            RightMotor_CmdVel = sat_value;
        }
        else if (RightMotor_CmdVel < 0){
            RightMotor_CmdVel = -sat_value;
        }
    }
    if (fabs(LeftMotor_CmdVel) > sat_value){
        if (LeftMotor_CmdVel > 0){
            LeftMotor_CmdVel = sat_value;
        }
        else if (LeftMotor_CmdVel < 0){
            LeftMotor_CmdVel = -sat_value;
        }
    }
}

Runtime Test

runstarttime = micros();
//****************************************************************
InverseKinematic(cmd_vel_linear, cmd_vel_angular, 0.39377, 0.085);
//****************************************************************
runtime = micros() - runstarttime;

Runtime: 0.004 ms
